| 说明 | Description |
Unit
|
ARES 110-S+
|
||
|
A
|
B
|
C
|
|||
| 射胶系统 | Injection Unit | ||||
| 螺杆直径 | Screw diameter |
mm
|
30
|
35
|
40
|
| 螺杆长径比 | Screw L/D ratio |
—
|
24.5
|
21
|
18.3
|
| 理论射胶容积 | Theoretical shot volume |
cm³
|
134
|
183
|
239
|
| 射胶量(PS) | Shot weight (PS) |
g
|
123
|
168
|
220
|
| 射胶压力 | lnjection pressure |
MPa
|
272
|
200
|
153
|
| 注射速率 | Injection rate |
g/s
|
83
|
96
|
125
|
| 螺杆行程 | Screw stroke |
mm
|
190
|
||
| 螺杆转速 | Screw speed |
rpm
|
205
|
||
| 锁模系统 | Clamping Unit | ||||
| 锁模力 | Clamping force |
kN
|
1100
|
||
| 推力座行程 | Opening stroke |
mm
|
360
|
||
| 导柱内距(水平×垂直) | Space between tie bars (HxV) |
mm
|
420 x 370
|
||
| 模板最大距离 | Max. daylight |
mm
|
780
|
||
| 最薄-最厚 | Mold thickness (Min-Max) |
mm
|
150 – 420
|
||
| 顶针行程 | Ejector stroke |
mm
|
120
|
||
| 顶针推力 | Ejector force |
kN
|
41
|
||
| 顶针杆根数 | Ejector number |
pcs
|
5
|
||
| 动力/电热 | Power/heating unit | ||||
| 系统压力 | System pressure |
MPa
|
17.5
|
||
| 伺服电机功率 | Motor pump capacity |
kW
|
13
|
||
| 电热功率 | Heating capacity |
kW
|
8
|
||
| 温度控制区数 | Number of temperature control zones |
—
|
3 + Nozzle
|
||
| 其它 | Others | ||||
| 料斗容积 | Hopper capacity |
L
|
25
|
||
| 油箱容量 | Oil tank capacity |
L
|
180
|
||
| 机身尺寸(长×宽×高) | Machine dimensions (L×W×H) |
m
|
4.7 x 1.3 x 1.65
|
||
| 机重 | Machine weight |
T
|
4.6
|
||
